CROSSES

PTFE Lined Crosses are produced with a free sintered liner and rotatable flanges. Standard shapes are carbon steel with stainless steel available upon request.

SIZE	A	B	C	D	NOTES
1	7.00	2.00	1	1
11/2	8.00	2.88	11/2	11/2
2	9.00	3.63	2	2
3	11.00	5.00	3	3
4	13.00	6.19	4	4
6	16.00	8.50	6	6
